Inverto Quad Monoblock 23mm LNB, 4.3° for 80cm dish

Inverto Quad Monoblock 23mm LNB, 4.3° for 80cm dish

69.99€
Ex Tax: 56.90€
Brand:Inverto
Product Code: 8PP-MNO43-QUDM21-IDLB
Stock Instock

Overview

Inverto Quad Monoblock 23mm LNB, 4.3° for 80cm dishThis Inverto Lnb was specifically designed for the European DTH markets, this Monoblock LNB allows for dual satellite reception. It can be ...

Inverto Quad Monoblock 23mm LNB, 4.3° for 80cm dish

This Inverto Lnb was specifically designed for the European DTH markets, this Monoblock LNB allows for dual satellite reception. It can be used for satellite broadcast reception (on an 80cm dish antenna) of the Astra 19.2°E and 23.5°E satellites spaced with 4.3°. This LNB enables the signal distribution to maximum four Set Top Boxes with Single Tuner (or two STBs with Twin Tuner). It is optimized for High Definition transmissions and provides excellent Noise Figure performance. Designed to meet strict specifications and manufactured to the highest industry quality standards, this LNB is an ideal solution for satellite broadcast reception across Europe.




Main features


Low Phase Noise, DVB-S2 (HDTV) compliant

Low Noise Figure (0.2 dB)

Low Power Consumption

High Cross Polarization isolation

High Frequency Stability


Technical specifications

Low band input frequency range 10.7 GHz ~ 11.7 GHz

Low band output frequency range 950 MHz ~ 1950 MHz

Low band LO frequency

9.75 GHz

High band input frequency range

11.7 GHz ~ 12.75 GHz

High band output frequency range - 1100 MHz ~ 2150 MHz

High band LO frequency - 10.6 GHz

Noise figure - 0.2 dB typ. (0.7 dB max.)

LO temperature drift - ±3.0 MHz Max.

LO accuracy @ 25 °C - ±1.0 MHz Max.

LO phase noise @ 10kHz - -90 dBc / Hz max.

Conversion gain - 50 dB ~ 65 dB

Gain ripple (over 26 MHz bandwidth) - ±0.75dB

Gain variation (over full band) - ±4dB max.

Image rejection - 40 dB min.

1 dB compression point (@ output) - 0.0 dBm min.

Control, Satellite A/B/C/D Selection - DiSEqC 1.0 (Sat A* = Astra 23.5° East, Sat B = Astra 19.2° East)

* Default Satellite Reception

Cross polarization isolation - 22 dB min.

Output VSWR - 2.5:1

In band spurious level - -60 dBm max.

Current consumption - 250 mA max. @ 11 V ~ 20 V

Operating temperature - -30 °C  ~  +60 °C

Output impedance - 75Ω

Output connector type - F-Type (female)

Recommended Dish Size - 80 cm (F/D = 0.6)

Weight - 485g

Packaging dimensions (W x D x H) - 14,3cm x 11,6cm x 10,8cm

Packaging weight - 0,625 kg

IDLB-QUDM22-DBA43-8PP /  8PP-MNO43-QUDM21-IDLB
Item nR.: 3535 / 3531
